Control
System |
Sensorless
Flux Vector PWM or VF Control |
|
Output
Frequency Range |
0.5
to 360 Hz |
|
Frequency
Resolution |
Digital
0.1 Hz - Analogue setting Max. Frequency divided by 1000 |
|
Starting
Torque |
High
Starting Torque of 200% or more (3.0kW+ : 180% or more) |
|
Braking |
Transistor
included, 20 -100% (capacitive feedback type) |
|
DC
Injection Braking |
Programmable
Power, Time & Frequency settings |
|
Speed
Reference |
Digital,
0-10Vdc (10K Ohm impedance), 4-20mA (250 Ohm impedance) |
|
Multi-stage
Speed |
16
Programmable Pre-sets |
|
Output
Voltage |
Same
as rated input + Auto Voltage Regulator (AVR) |
|
Accel/Deccel |
0.1-3000s
linear or S Curve - 2 selectable |
|
Input
Terminals |
6
Programmable from 19 selections |
|
Output
Terminals |
2
Programmable from 6 selections • Open Collector 27Vdc 50mA |
|
Alarm
Relay |
Change
over contact. |
|
Meter
Output |
Voltage
or Frequency Output of Speed or Load indication only. |
|
Protection |
15
functions inc- earth fault |
|
Trip
History |
Last
3 trips, total trip log |
|
PID
Control |
Programmable
PID function - 4-20mA / 0-IOVdc feedback. |
|
Enclosure |
IP20 |
|
International
Standards |
UL.
C-UL (CSA), CE and C-Tick - Complies with EMC & LV Directives. |
|
Model Number |
Motor
Power |
Rated
Current |
Unit Price |
|
RFI Filter Model |
Unit Price |
|
200-240V 1/3ph input |
||||||
|
V2000 002NFE |
0.2kW |
1.6A |
£155.00 |
FP 1PH 0.2/0.5V |
£24.00 |
|
|
V2000 004NFE |
0.4kW |
2.6A |
£165.00 |
FP 1PH 0.2/0.5V |
£24.00 |
|
|
V2000 005NFE |
0.55kW |
3.0A |
£191.00 |
FP 1PH 0.2/0.5V |
£24.00 |
|
|
V2000 007NFE |
0.75kW |
4.0A |
£212.00 |
FP 1PH 0.5L/1.1V |
£28.00 |
|
|
V2000 011NFE |
1.lkW |
5.0A |
£243.00 |
FP 1PH 0.5L/1.1V |
£28.00 |
|
|
V2000 015NFE |
1.5kW |
8.0A |
£268.00 |
FP 1PH 1.1L/2.2 |
£36.00 |
|
|
V2000 022NFE |
2.2kW |
11.0A |
£325.00 |
FP 1PH 1.1L/2.2 |
£36.00 |
|
|
380-400V 3ph input |
||||||
|
V2000 004HFE |
0.4kW |
1.5A |
£283.00 |
|
FP 3PH 0.4/2.2V |
£48.00 |
|
V2000 007HFE |
0.75kW |
2.5A |
£335.00 |
FP 3PH 0.4/2.2V |
£48.00 |
|
|
V2000 015HFE |
1.5kW |
3.8A |
£371.00 |
FP 3PH 0.4/2.2V |
£48.00 |
|
|
V2000 022HFE |
2.2kW |
5.5A |
£443.00 |
FP 3PH 0.4/2.2V |
£48.00 |
|
|
V2000 030HFE |
3.0kW |
7.8A |
£490.00 |
FP 3PH 2.2L/4.0 |
£60.00 |
|
|
V2000 040HFE |
4.0kW |
8.6A |
£541.00 |
FP 3PH 2.2L/4.0 |
£60.00 |
|
|
V2000 055HFE |
5.5kW |
13.0A |
£706.00 |
FP 3PH 5.5/7.5 |
£79.00 |
|
|
V2000 075HFE |
7.5kW |
16.0A |
£845.00 |
FP 3PH 5.5/7.5 |
£79.00 |
|
|
|||||||||
|
